F4/80 Recombinant Rabbit Monoclonal Antibody [PSH01-87]

Quota

Contact Us

Email: [email protected]

Phone: 0571-88062880

Find Local Distributors

Catalog# HA721745

F4/80 Recombinant Rabbit Monoclonal Antibody [PSH01-87]

Application

  • WB

  • IHC-P

  • IF-Tissue

  • IHC-Fr

Reactivity

  • Mouse

This product has been cited in peer reviewed publications, see list HERE

Overview

Product Name

F4/80 Recombinant Rabbit Monoclonal Antibody [PSH01-87]

Antibody Type

Recombinant Rabbit monoclonal Antibody

Immunogen

Recombinant protein within mouse F4/80 aa 1-650 / 931.

Species Reactivity

Mouse

Validated Applications

WB, IHC-P, IF-Tissue, IHC-Fr

Molecular Weight

Predicted band size: 102 kDa

Positive Control

RAW264.7 cell lysate (no heat), mouse liver tissue, mouse spleen tissue.

Conjugation

unconjugated

Clone Number

PSH01-87

RRID

AB_3072857

Product Features

Form

Liquid

Concentration

1ug/ul

Storage Instructions

Store at +4℃ after thawing. Aliquot store at -20℃. Avoid repeated freeze / thaw cycles.

Storage Buffer

PBS (pH7.4), 0.1% BSA, 40% Glycerol. Preservative: 0.05% Sodium Azide.

Isotype

IgG

Purification Method

Protein A affinity purified.

Application Dilution

  • WB

  • 1:1,000

  • IHC-P

  • 1:5,000

  • IF-Tissue

  • 1:500

  • IHC-Fr

  • 1:500-1:1,000

Applications in Publications

IF See 1 publications below

Species in Publications

Mouse See 1 publications below

Target

Function

EGF-like module-containing mucin-like hormone receptor-like 1 also known as F4/80 is a protein encoded by the ADGRE1 gene. EMR1 is a member of the adhesion GPCR family. Adhesion GPCRs are characterized by an extended extracellular region often possessing N-terminal protein modules that is linked to a TM7 region via a domain known as the GPCR-Autoproteolysis INducing (GAIN) domain. EMR1 expression in human is restricted to eosinophils and is a specific marker for these cells. The murine homolog of EMR1, F4/80, is a well-known and widely used marker of murine macrophage populations. The N-terminal fragment (NTF) of EMR1 contains 4-6 Epidermal Growth Factor-like (EGF-like) domains in human and 4-7 EGF-like domains in the mouse. Utilizing F4/80 knockout mice, Lin et al. showed that F4/80 is not necessary for the development of tissue macrophages but is required for the induction of efferent CD8+ regulatory T cells needed for peripheral tolerance.

Background References

1. Wang J, Wu X, Dai W, et al. The CCDC43-ADRM1 axis regulated by YY1, promotes proliferation and metastasis of gastric cancer. Cancer Lett. 2020 Jul 10; 482:90-101.

2. Fejzo MS, Anderson L, von Euw EM, et al. Amplification Target ADRM1: Role as an Oncogene and Therapeutic Target for Ovarian Cancer. Int J Mol Sci. 2013 Feb 1;14(2):3094-109.

Subcellular Location

Cell membrane.

UNIPROT

SwissProt: Q61549 Mouse

Synonyms

ADGRE1 antibody

Adhesion G protein coupled receptor E1 antibody

Adhesion G protein-coupled receptor E1 antibody

AGRE1_HUMAN antibody

Cell surface glycoprotein EMR1 antibody

Cell surface glycoprotein F4/80 antibody

DD7A5 7 antibody

Egf like module containing mucin like hormone receptor like 1 antibody

Egf like module containing mucin like hormone receptor like sequence 1 antibody

EGF like module receptor 1 antibody

Expand

Images

  • Western blot analysis of F4/80 on RAW264.7 cell lysate (no heat) with Rabbit anti-F4/80 antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/1,000 dilution.<br /><br />Notice: no heat means the lysate is not boiled.<br /><br />Lysates/proteins at 20 µg/Lane.<br /><br />Predicted band size: 102 kDa<br />Observed band size: 160 kDa<br /><br />Exposure time: 5 minutes;<br /><br />4-20% SDS-PAGE gel.<br /><br />Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/1,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (<a href="/products/HA1001" style="font-weight: bold;text-decoration: underline;">HA1001</a>) at 1/50,000 dilution was used for 1 hour at room temperature.

    Western blot analysis of F4/80 on RAW264.7 cell lysate (no heat) with Rabbit anti-F4/80 antibody (HA721745) at 1/1,000 dilution.

    Notice: no heat means the lysate is not boiled.

    Lysates/proteins at 20 µg/Lane.

    Predicted band size: 102 kDa
    Observed band size: 160 kDa

    Exposure time: 5 minutes;

    4-20% SDS-PAGE gel.

    Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (HA721745) at 1/1,000 dilution was used in 5% NFDM/TBST at 4℃ overnight. Goat Anti-Rabbit IgG - HRP Secondary Antibody (HA1001) at 1/50,000 dilution was used for 1 hour at room temperature.

  • Immunohistochemical analysis of paraffin-embedded mouse liver tissue with Rabbit anti-F4/80 antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/5,000 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded mouse liver tissue with Rabbit anti-F4/80 antibody (HA721745) at 1/5,000 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA721745) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

  • Immunohistochemical analysis of paraffin-embedded mouse spleen tissue with Rabbit anti-F4/80 antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/5,000 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded mouse spleen tissue with Rabbit anti-F4/80 antibody (HA721745) at 1/5,000 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA721745) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

  • Immunohistochemical analysis of paraffin-embedded mouse lung tissue with Rabbit anti-F4/80 antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/5,000 dilution.<br /><br />The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH<sub>2</sub>O and PBS, and then probed with the primary antibody (<a href="/products/HA721745" style="font-weight: bold;text-decoration: underline;">HA721745</a>) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

    Immunohistochemical analysis of paraffin-embedded mouse lung tissue with Rabbit anti-F4/80 antibody (HA721745) at 1/5,000 dilution.

    The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (HA721745) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

  • Application: IHC-Fr<br /><br />Species: Mouse<br /><br />Site: Liver<br /><br />Sample: Frozen section<br /><br />Antibody concentration: 1/1,000<br /> <br />Antigen retrieval: Not required

    Application: IHC-Fr

    Species: Mouse

    Site: Liver

    Sample: Frozen section

    Antibody concentration: 1/1,000

    Antigen retrieval: Not required

  • Application: IHC-Fr<br /><br />Species: Mouse<br /><br />Site: Spleen<br /><br />Sample: Frozen section<br /><br />Antibody concentration: 1/1,000<br /> <br />Antigen retrieval: Not required

    Application: IHC-Fr

    Species: Mouse

    Site: Spleen

    Sample: Frozen section

    Antibody concentration: 1/1,000

    Antigen retrieval: Not required

  • Application: IF-tissue<br /><br />Species: Mouse<br /><br />Site: Liver<br /><br />Sample: Paraffin-embedded section<br /><br />Antibody concentration: 1/500

    Application: IF-tissue

    Species: Mouse

    Site: Liver

    Sample: Paraffin-embedded section

    Antibody concentration: 1/500

  • Application: IF-tissue<br /><br />Species: Mouse<br /><br />Site: Spleen<br /><br />Sample: Paraffin-embedded section<br /><br />Antibody concentration: 1/500

    Application: IF-tissue

    Species: Mouse

    Site: Spleen

    Sample: Paraffin-embedded section

    Antibody concentration: 1/500

Please note: All products are "FOR RESEARCH USE ONLY AND ARE NOT INTENDED FOR DIAGNOSTIC OR THERAPEUTIC USE"
